zra-kyyp-4*1.5控制电缆KVVP屏蔽控制电缆和相比，多一层编织屏蔽，P就代表屏蔽。
● 用于自动控制或监测系统、电器仪表连接等场合用传输线
● 无氧铜丝单根粗导体
● 导体单根整体较硬
● 铜网编织屏蔽
zra-kyyp-4*1.5控制电缆结构：
导体：单根粗铜丝或多根精细铜丝
绝缘：PVC绝缘
填充物：PP带或无纺布包裹缓冲
屏蔽：铜网编织屏蔽
护套：PVC护套
颜色：黑色（RAL9005）
额定电压： 450/750V
测试电压： 3000V
使用温度范围：
移动安装：-10℃~+70℃ 固定安装：-30℃~+70℃
结构示意图
规格型号，技术参数
铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽控制电缆 | ||||||||||
铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽控制电缆（KVVP） | ||||||||||
芯数及导体标称截面 | 导体结构 | 绝缘厚度 | 屏蔽铜丝直径 | 护套厚度 | 电缆近似外径 | 电缆近似重量 | ||||
NO./фmm | mm | mm | mm | mm | kg/km | |||||
mm2 | - | 450/750V | 0.6/1kV | - | 450/750V | 0.6/1kV | 450/750V | 0.6/1kV | 450/750V | 0.6/1kV |
6×0.75 | 7/0.37 | 0.6 | 0.8 | 0.15 | 1.2 | 1.8 | 10.4 | 12.6 | 154 | 213 |
6×1 | 7/0.43 | 0.6 | 0.8 | 0.15 | 1.2 | 1.8 | 10.9 | 13.2 | 177 | 238 |
6×1.5 | 7/0.52 | 0.7 | 0.8 | 0.15 | 1.5 | 1.8 | 12.9 | 14 | 247 | 281 |
6×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.5 | 1.8 | 15.2 | 15.6 | 364 | 385 |
6×4 | 7/0.85 | 0.8 | 1 | 0.2 | 1.5 | 1.8 | 16.7 | 18.4 | 485 | 552 |
6×6 | 7/1.04 | 0.8 | 1 | 0.2 | 1.5 | 1.8 | 18.4 | 20.1 | 633 | 705 |
6×10 | 1/1.35 | 1 | 1 | 0.2 | 1.7 | 1.8 | 22.8 | 22.9 | 993 | 1004 |
7×0.75 | 7/0.37 | 0.6 | 0.8 | 0.15 | 1.2 | 1.8 | 10.4 | 12.6 | 163 | 223 |
7×1 | 7/0.43 | 0.6 | 0.8 | 0.15 | 1.2 | 1.8 | 10.9 | 13.2 | 188 | 251 |
7×1.5 | 7/0.52 | 0.7 | 0.8 | 0.15 | 1.5 | 1.8 | 12.9 | 14 | 263 | 298 |
7×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.5 | 1.8 | 15.2 | 15.6 | 392 | 413 |
7×4 | 7/0.85 | 0.8 | 1 | 0.2 | 1.5 | 1.8 | 16.7 | 18.4 | 526 | 594 |
7×6 | 7/1.04 | 0.8 | 1 | 0.2 | 1.5 | 1.8 | 18.4 | 20.1 | 691 | 766 |
7×10 | 1/1.35 | 1 | 1 | 0.2 | 1.7 | 1.8 | 22.8 | 22.9 | 1091 | 1101 |
8×0.75 | 7/0.37 | 0.6 | 0.8 | 0.15 | 1.2 | 1.8 | 11.1 | 13.4 | 183 | 250 |
8×1 | 7/0.43 | 0.6 | 0.8 | 0.15 | 1.5 | 1.8 | 12.3 | 14 | 229 | 283 |
8×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.5 | 1.8 | 14 | 15.1 | 313 | 353 |
8×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.5 | 1.8 | 16.3 | 16.7 | 445 | 467 |
8×4 | 7/0.85 | 0.8 | 1 | 0.2 | 1.7 | 1.8 | 18.3 | 19.7 | 603 | 663 |
8×6 | 7/1.04 | 0.8 | 1 | 0.2 | 1.7 | 1.8 | 20.2 | 21.6 | 792 | 856 |
8×10 | 1/1.35 | 1 | 1 | 0.25 | 1.7 | 1.8 | 24.8 | 24.9 | 1252 | 1263 |
10×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 13.5 | 15.5 | 255 | 320 |
10×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 14.2 | 16.3 | 294 | 361 |
10×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.5 | 1.8 | 16.1 | 17.3 | 382 | 430 |
10×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.5 | 1.8 | 18.8 | 19.3 | 547 | 572 |
10×4 | 7/0.85 | 0.8 | 1 | 0.2 | 1.7 | 1.8 | 21.3 | 22.9 | 743 | 816 |
10×6 | 7/1.04 | 0.8 | 1 | 0.25 | 1.7 | 1.8 | 23.7 | 25.4 | 1005 | 1086 |
10×10 | 1/1.35 | 1 | 1 | 0.25 | 1.7 | 1.8 | 29.1 | 29.3 | 1552 | 1578 |
12×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 13.8 | 16 | 282 | 352 |
12×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 14.6 | 16.7 | 326 | 400 |
12×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.5 | 1.8 | 16.5 | 17.8 | 428 | 479 |
12×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.7 | 1.8 | 19.8 | 19.8 | 636 | 654 |
12×4 | 7/0.85 | 0.8 | 1 | 0.2 | 1.7 | 1.8 | 21.9 | 23.6 | 846 | 928 |
12×6 | 7/1.04 | 0.8 | 1 | 0.25 | 1.7 | 1.8 | 24.5 | 26.2 | 1150 | 1241 |
14×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 14.4 | 16.7 | 313 | 390 |
14×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 15.2 | 17.5 | 364 | 444 |
14×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.5 | 1.8 | 17.3 | 18.6 | 479 | 535 |
14×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.7 | 1.8 | 20.7 | 20.8 | 717 | 726 |
14×4 | 7/0.85 | 0.8 | 1 | 0.2 | 1.7 | 1.8 | 23 | 24.8 | 959 | 1050 |
14×6 | 7/1.04 | 0.8 | 1 | 0.25 | 1.7 | 1.8 | 25.7 | 27.5 | 1306 | 1409 |
●铜芯聚氯乙烯绝缘聚氯乙烯护套编织屏蔽控制电缆（KVVP） | ||||||||||
芯数及导体标称截面 | 导体结构 | 绝缘厚度 | 屏蔽铜丝直径 | 护套厚度 | 电缆近似外径 | 电缆近似重量 | ||||
NO./фmm | mm | mm | mm | mm | kg/km | |||||
mm2 | - | 450/750V | 0.6/1kV | - | 450/750V | 0.6/1kV | 450/750V | 0.6/1kV | 450/750V | 0.6/1kV |
16×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 15.1 | 17.4 | 345 | 429 |
16×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 16 | 18.3 | 402 | 490 |
16×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.5 | 1.8 | 18.2 | 19.6 | 533 | 593 |
16×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.7 | 1.8 | 21.8 | 21.8 | 800 | 809 |
19×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 15.8 | 18.3 | 383 | 475 |
19×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 16.7 | 19.2 | 450 | 546 |
19×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.7 | 1.8 | 19.5 | 20.5 | 616 | 665 |
19×2.5 | 7/0.68 | 0.8 | 0.8 | 0.2 | 1.7 | 1.8 | 22.9 | 22.9 | 904 | 914 |
24×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 18.1 | 21 | 469 | 581 |
24×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.7 | 1.8 | 19.6 | 22 | 570 | 670 |
24×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.7 | 1.8 | 22.4 | 23.7 | 759 | 818 |
24×2.5 | 7/0.68 | 0.8 | 0.8 | 0.25 | 1.7 | 1.8 | 26.7 | 26.7 | 1150 | 1162 |
27×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.5 | 1.8 | 18.5 | 21.4 | 508 | 628 |
27×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.7 | 1.8 | 20 | 22.5 | 618 | 726 |
27×1.5 | 7/0.52 | 0.7 | 0.8 | 0.2 | 1.7 | 1.8 | 22.9 | 24.1 | 827 | 891 |
27×2.5 | 7/0.68 | 0.8 | 0.8 | 0.25 | 1.7 | 1.8 | 27.3 | 27.3 | 1258 | 1271 |
30×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.7 | 1.8 | 19.5 | 22.1 | 568 | 679 |
30×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.7 | 1.8 | 20.6 | 23.2 | 670 | 787 |
30×1.5 | 7/0.52 | 0.7 | 0.8 | 0.25 | 1.7 | 1.8 | 23.8 | 25.2 | 926 | 997 |
30×2.5 | 7/0.68 | 0.8 | 0.8 | 0.25 | 1.7 | 1.8 | 28.2 | 28.2 | 1373 | 1385 |
37×0.75 | 7/0.37 | 0.6 | 0.8 | 0.2 | 1.7 | 1.8 | 20.8 | 23.7 | 666 | 797 |
37×1 | 7/0.43 | 0.6 | 0.8 | 0.2 | 1.7 | 1.8 | 22.1 | 24.9 | 790 | 928 |
37×1.5 | 7/0.52 | 0.7 | 0.8 | 0.25 | 1.7 | 1.8 | 25.6 | 27 | 1096 | 1179 |
37×2.5 | 7/0.68 | 0.8 | 0.8 | 0.25 | 2 | 2 | 30.9 | 30.8 | 1679 | 1679 |
44×0.75 | 7/0.37 | 0.6 | 0.8 | 0.25 | 1.7 | 1.8 | 23.3 | 26.6 | 803 | 960 |
44×1 | 7/0.43 | 0.6 | 0.8 | 0.25 | 1.7 | 1.8 | 24.8 | 28 | 952 | 1117 |
44×1.5 | 7/0.52 | 0.7 | 0.8 | 0.25 | 1.7 | 1.9 | 28.5 | 30.4 | 1284 | 1395 |
44×2.5 | 7/0.68 | 0.8 | 0.8 | 0.3 | 2 | 2.1 | 34.8 | 34.8 | 2011 | 2027 |
48×0.75 | 7/0.37 | 0.6 | 0.8 | 0.25 | 1.7 | 1.8 | 23.7 | 27 | 854 | 1021 |
48×1 | 7/0.43 | 0.6 | 0.8 | 0.25 | 1.7 | 1.8 | 25.2 | 28.5 | 1015 | 1191 |
48×1.5 | 7/0.52 | 0.7 | 0.8 | 0.25 | 1.7 | 1.9 | 29 | 30.9 | 1374 | 1491 |
48×2.5 | 7/0.68 | 0.8 | 0.8 | 0.3 | 2 | 2.1 | 35.3 | 35.4 | 2155 | 2171 |
52×0.75 | 7/0.37 | 0.6 | 0.8 | 0.25 | 1.7 | 1.8 | 24.3 | 27.7 | 909 | 1087 |
52×1 | 7/0.43 | 0.6 | 0.8 | 0.25 | 1.7 | 1.9 | 25.8 | 29.4 | 1082 | 1282 |
52×1.5 | 7/0.52 | 0.7 | 0.8 | 0.25 | 2 | 2 | 30.4 | 31.9 | 1508 | 1606 |
52×2.5 | 7/0.68 | 0.8 | 0.8 | 0.3 | 2.2 | 2.2 | 36.7 | 36.5 | 2338 | 2338 |
61×0.75 | 7/0.37 | 0.6 | 0.8 | 0.25 | 1.7 | 1.9 | 25.6 | 29.5 | 1032 | 1248 |
61×1 | 7/0.43 | 0.6 | 0.8 | 0.25 | 1.7 | 2 | 27.3 | 31.3 | 1233 | 1474 |
61×1.5 | 7/0.52 | 0.7 | 0.8 | 0.25 | 2 | 2 | 32.1 | 33.7 | 1722 | 1834 |
61×2.5 | 7/0.68 | 0.8 | 0.8 | 0.3 | 2.2 | 2.2 | 38.8 | 38.7 | 2678 | 2678 |
